ANOEKO AOK-C06B Passive Counter UAS System | Drone Detection & RF Jamming All-in-One Device

ANOEKO AOK-C06 Integrated Drone Detection & Countermeasure System

ANOEKO AOK-C06 is an all-in-one counter-UAV solution assembled by independent detection chassis and jamming chassis via connecting cables, integrating AI algorithm analysis, protocol decoding and wideband spectrum monitoring technology to identify mainstream consumer-grade drones and FPV racing drones on the global market.

Compliant with international standards including GB42590-2023, ASD-STAN prEN 4709-002 and ASTM F3411, this system can extract complete flight data of DJI OcuSync1/OcuSync2 drones: GPS coordinates, flight altitude, flying speed, heading, drone model, SN serial number, takeoff location and real-time distance between UAV and detector.

Its jamming module supports customized frequency bands and output power based on client demands. The jamming unit keeps standby with zero RF emission when no illegal drones are spotted; once unauthorized UAV intrusion is detected, users can enable auto or manual RF suppression to force target drones to return or land.

Core Advantages

1. Multi-mode Passive      Silent Detection:      No electromagnetic radiation during scanning, adopts hybrid detection      technology for fast identification of DJI, Autel, Hubsan, FIMI, FPV and      DIY UAVs;

2. Precise Data Acquisition: Real-time capture full      flight parameters for standard-compliant drones, color-coded trajectory      display for multi-drone swarm tracking;

3. Black & White List      Configuration:      Add UAV SN codes into whitelist to avoid unnecessary jamming on authorized      in-house drones while alerting blacklisted rogue UAVs;

4. Dual Alert Mechanism: Audible + visual alarm      triggers immediately upon unauthorized drone intrusion;

5. 12-Channel Independent      Jamming Control:      Separate switch for each jamming channel, exempt designated authorized      drone frequency bands from suppression;

6. Short-time Selective      Interference:      Jamming lasts within 3 minutes only after target confirmation to save      power and minimize environmental spectrum interference;

7. Data Retention Function: Full historical      detection log storage and flight track playback available for post-event      analysis;

8. Fast Field Deployment: Compact structure for      quick setup and easy operation for temporary or fixed-site defense.

Technical Specifications
