Product Overview

The ANOEKO AOK-T7 portable handheld drone detector integrates drone signal detection and multi-satellite navigation positioning into a single compact handheld unit. As a professional counter drone detection instrument, this portable drone detector performs deep signal analysis and feature recognition to identify commercial UAVs, self-assembled DIY drones and FPV drones within its effective detection range.

This anti UAV security system detector can decode critical UAV data, including drone model, serial number (SN), and real-time position of both the drone and remote pilot. Vibration and audio dual alarm modes deliver instant warning alerts for low-altitude airspace protection.

Lightweight and tactical-friendly, the AOK-T7 handheld drone detector powers up and starts detection automatically. Equipped with a 4-inch high-bright outdoor color LCD screen, multi-functional offline mapping, flexible connectivity and dual power supply design, the device supports smooth one-handed operation for security personnel in field missions.

Product Features

Full-Spectrum Passive Detection

The AOK-T7 drone signal detector covers 70MHz to 6000MHz frequency band, with 12 preset frequency bands and support for customized frequency expansion. Adopting passive radio frequency detection without signal transmission, it keeps the detection mission concealed. It scans full spectrum continuously to capture analog and digital video transmission signals of various drones with low false alarm rate, and displays all signal data in real time for operators.

Precision Localization & Multi-Mode Navigation

Built-in multi-mode satellite navigation supports BDS, GPS, GLONASS, Galileo and QZSS. Combined with optional directional antenna and self-developed spectrum analysis algorithm, this drone detection defense equipment realizes fast and accurate UAV identification and direction finding.

Rugged Hardware & Long Endurance

IP55 industrial protection rating supports operation under harsh environments, with operating temperature range from -20℃ to 50℃. The handheld drone detector weighs ≤900g, supports over 4 hours continuous work with screen on and more than 6 hours standby with screen off. Quick-release rechargeable battery and external power supply form dual power supply mode for extended field deployment.

Rich Data & Expandable Functions

The device supports TF card local storage, historical data statistics, playback and data export in Excel format. Users can complete one-click software upgrade through Type-C web interface. Multiple language options are available, default in English and Chinese, with more languages customizable.

Core Parameters
